Specifications
| Part number | Inductance (nH) | Tolerance (%) | 900 MHz | 1.7 GHz |
Q min
@ 250 MHz |
SRF min (GHz) | DCR max (mΩ) | Imax (mA) | ||
|---|---|---|---|---|---|---|---|---|---|---|
| L typ | Q typ | L typ | Q typ | |||||||
| ST312RAK5N1_RZ | 5.1 | 5,2 | 5120 | 68 | 5180 | 93 | 23 | 4.4 | 50.0 | 800 |
Notes
Environmental
Failures in Time (FIT) / Mean Time Between Failures (MTBF):
